Adastra Rmc120d Rmc120 Mixer-amp 120w With Cd/usb/sd/fm

Adastra Rmc120d - Rmc120 Mixer-amp 120w With Cd/usb/sd/fm

100V line mixer-amplifier with built-in multi-format media player. 5 input channels include a balanced XLR microphone input with switchable phantom power and Vox override, 2 mic/line jack inputs and 2 RCA line inputs. A powerful class AB amplifier section is paired with a digital switch-mode power supply and 100V transformer for reliable power delivery from an energy efficient power section. A built-in CD player provides audio playback alongside a USB/SD media player with an integral DAB+ and FM radio tuner. Additional Bluetooth receiver enables pairing to a smartphone for wireless playback of stored tracks. Bass & Treble EQ and Master volume control the overall output, which can power either low impedance or 100V line speakers. A comprehensive solution for commercial sound installations.

Features

• 5 input channels
• DAB+ and FM radio tuner
• Slot feed CD player
• Bluetooth connectivity
• USB/SD mp3 player
• 100V or 4-16 Ohms output
• Supplied with 19" rack-mount ears

Technical Specifications

• Power supply : 170-264Vac, 50Hz (IEC)
• DC power : 24Vdc (screw terminals)
• Power : rms : 120Wrms (100V or 4 Ohms)
• Inputs : Mic XLR, 2 x mic/line jack, 2 x RCA line
• Input sensitivity : mic 1 (balanced) : -53dBV
• Input impedance : mic 1 : 5k Ohms
• Input sensitivity : line (unbalanced) : -15dBV (-18.5dBV line 5)
• Input impedance : inputs 2-5 : 1k Ohms
• Line output : RCA
• Controls : Mic1, mic/line2+3, line4+5 (USB), bass, treble, master volume
• Speaker outputs : 100V / 4-16 Ohms / COM terminals
• Equaliser : bass : 100Hz +/-10dB
• Equaliser : treble : 10kHz +/-10dB
• Rear panel switches : Mic/Line (2 + 3), Phantom, Vox
• Phantom power : +20V (MIC 1 input)
• Bluetooth version : 5.0
• THD :
