Cloud 46/80 4 Zone (4x80w) Integrated Mixer Amplifier

Cloud 46/80 4 Zone (4x80w) Integrated Mixer Amplifier

The Cloud 46-80 is a versatile, four-zone, rack-mounting (2U) audio mixing amplifier. It combines simple control of background music, microphone paging and power amplification for up to four zones in a single unit. It has extensive remote control facilities and is ideal for installation in premises such as pubs, bars, hotels, clubs, leisure and fitness centres, retail and other commercial premises, etc. The 46-80 has four mono zone outputs, each driven by an 80 W (nominal rating) power amplifier stage: if less than four separate zones are required, the power stages may be paralleled by moving internal jumpers to permit dual stereo, quad mono or stereo + dual mono operation, with accordingly increased output power. The power stages have extensive protection circuitry to safeguard both the amplifier and loudspeakers.

• Eight input (6 x line, 2 x mic) mixing amplifier for four zones
• Zone 1 Facility Port for connection of optional remote input plates: LM-2 mic/line input + music controls, BT-1 Bluetooth input, L-1 line input, M-1 mic input
• Music Mute control input (N/O

• Product EAN 0000000000000
• Power Input (V @50 Hz) 70
• Input Impedance 80 W into 4 ohms
• Frquency response 20 Hz to 20 kHz
• Item priced per 1
• Sensitivity (dB) 195 mV (-12 dBu) to 2.0 V (+8 dBu)
• Product Dimensions (mm) 483x88x320
• Impedance (Ohms) 4
• Power RMS (W) 4X80W

• Eight input (6 x line, 2 x mic) mixing amplifier for four zones
• Zone 1 Facility Port for connection of optional remote input plates: LM-2 mic/line input + music controls, BT-1 Bluetooth input, L-1 line input, M-1 mic input
• Music Mute control input (N/O
