Avlink Hdr4kv2 4k Hdmi 2.0 Repeater

Avlink Hdr4kv2 - 4k Hdmi 2.0 Repeater

A compact 4K HDMI repeater to connect HDMI cables of up to 40m combined length with minimal signal degradation. Combine up to 10m cable for 4K@60Hz resolution, or up to 40m for 4K@30Hz and FHD resolutions. This updated version will support HDMI v2.0 which is compatible with the latest 4K digital TV boxes producing 3840 x 2160 @ 60Hz resolution.

Features

• Maintains 4K@60Hz resolution without signal loss over combined 10m cable length
• Maintains 4K@30Hz and FHD resolution without signal loss over combined 40m cable length
• Easy connection and installation
• Supports HDMI v2.0b resolutions up to 3840x 2160 @ 60Hz
• Supports DTS-HD, Dolby True, DTS, Dolby-AC3 and DSD audio formats
• No external power source required
• NOTE: poor quality HDMI cables will affect the maximum resolution and transmission distance

Technical Specifications

• HDMI version : v2.0b
• HDCP version : 2.2
• Video resolution : Up to 3840 x 2160P @ 60Hz
• Audio format : DTS-HD, Dolby True, DTS, Dolby-AC3 and DSD
• Max. bandwidth : 600Mhz
• Max. baud rate : 3x 6Gbps
• Transmission distance : 10m 4K@60Hz (5m input/5m output), 40m 4K@30Hz and 1080p (20m input/20m output)
• Max. working current : 300mA
• Dimensions : 50 x 30 x 18mm
• Weight : 21g
