Citronic Cx34 Active Crossover 2 / 3 / 4-way

Citronic Cx34 - Cx34 Active Crossover 2 / 3 / 4-way

The CX34 is a 2 or 3-way stereo or 4-way mono active crossover designed to split frequencies so that low frequencies are delivered to the amp driving the sub cabinets and mid/top frequencies are delivered to the amp driving the mid/top frequency cabs. This type of system is more efficient and delivers more accurate sound quality, especially in larger PA systems.

Features

• 2 or 3-way stereo, 4-way mono crossover
• 19" rack mountable
• Linkwitz-Riley 24dB/octave, state variable
• Continuously adjustable cutoff frequencies
• 40Hz ultra-low frequency cut
• Phase invert function
• Inputs and outputs via XLR

Technical Specifications

• Power supply : 115/230Vac, 50/60Hz (IEC)
• Input impedance : balanced : 50k ohms
• Input impedance : unbalanced : 25k ohms
• Output impedance : 200 ohms
• Crossover ranges : 45-960Hz (switchable 10x) or 450Hz-9.6kHz
• Filter slope : 24dB/octave
• Frequency response : 20Hz - 20KHz, +0/-0.5dB
• Signal to noise ratio : >90dB
• THD :
