Mercury Ims300-12 12vdc 300w Modified Sine Wave Inverter

Mercury Ims300-12 - 12vdc 300w Modified Sine Wave Inverter

These high efficiency power inverters use a modified sine wave to power 230V mains equipment from a 12V or 24V battery or DC power supply. Perfect for use while camping, in commercial vans/lorries, or as a means to convert charged batteries for back-up power in case of a blackout. Ideal for use with TVs, lighting, fans, kettles and many other everyday appliances.

Features

• Low/over voltage input protection
• Short circuit, overload and overheat protection
• Built in 1000mA USB socket
• Over 85% efficiency
• Soft start minimises inverter shutdown when using large inductive loads
• LED and audible fault indicator
• Supplied with 1 pair of 800mm DC power cables and a spare blade fuse (2 pairs for 1500W and 2500W)
• Please note: For equipment with inductive loads, voltage sensitive devices or audio equipment we recommend using pure sine wave inverters which are more suitable for these devices
• 12V or 24V input versions available, please ensure the correct version is selected for the input power to be used
• Please note: Ensure the device is well within the inverter output power rating. We recommend using an inverter capable of supplying a minimum of 3 times the device's rated power to avoid damage to the inverter by any current surge

Technical Specifications

• Output voltage : 230Vac, 50Hz
• USB output current : 1A
• Weight : 650g
• Continuous power : 300W
• Dimensions : 160 x 103 x 55mm
• Cable type : Crocodile clip
• Standby no load current : <0.3A
• Output sockets : 1
• Input voltage : 10.8 - 15.5Vdc
• Voltage : 12V
• Inverter terminals : M6 screws
• Cable terminals : 72mm crocodile clip + 6.4/12mm ring
